DICOM in digital pathology

The DICOM standard will allow seamless integration of digital pathology scanners with viewers, AI applications, PACS and Vendor-neutral archives (VNAs) from different vendors. While it is still possible to share proprietary WSIs between systems without DICOM, all vendors would need to adapt their system to work with each unique proprietary file format. Philips has been and will continue to support this with a public Software Development Kit (SDK) and a free iSyntax File Viewer.¹

Philips was the world’s first vendor to release an IVD-labeled digital pathology system (both CE-IVD in 2013 and an FDA DeNovo clearance in 2017). This required close collaboration with regulators to set up a new regulatory framework to be used by the rest of the industry. Since digital pathology is a relatively new digital imaging modality compared to radiology and other modalities, there was no DICOM standard and all digital pathology vendors have developed their own proprietary format. No labs currently use DICOM images exclusively on an end-to-end digital pathology solution for primary diagnosis.

The DICOM standard is intended to realize interoperability among scanners, viewers and other pathology systems. Regulators (FDA) require a closed end-to-end system, consisting of a scanner, image viewer and monitor, to be tested as one entity. This is why it remains a challenge for vendors to introduce an open ecosystem that allows interoperability while at the same time remaining compliant with regulatory requirements.

A typical DICOM file contains patient and study/case information. Because DICOM follows the radiology context, this data is already known during image acquisition. This is not the case in the digital pathology workflow, since scans can be made without upfront patient or study/case information. A standalone digital pathology scanner cannot read DICOM data, so specific software is needed to read and produce a complete DICOM file with study/data from a laboratory information system (LIS). Working Group 26 is still discussing a solution for this. Not all PACS/VNAs are ready to support WSIs due to the unique attributes and file size. Philips intends to integrate the PACS/VNA into its digital pathology solution.

Philips strongly supports standardization and is a member of Working Group 26, which is tasked to support, develop and test DICOM standards for whole slide images (WSIs). Philips contributed to Supplements 145 and 122 for WSI. In addition, Philips is a member of the Digital Pathology Association (DPA) Regulatory and Standard Task Force.

Philips enables a DICOM export that converts its iSyntax format to a lossless, DICOM-compliant JPEG2000 file.¹ Philips DICOM files have proven successful during the DICOM Connectathons in the last seven years. We successfully tested an improved DICOM export during the 2023 Connectathon. More information can be found in the Philips IntelliSite Pathology Solution DICOM Conformance Statement that includes detailed information on DICOM files.

To ensure an open ecosystem for digital pathology without compromising quality, safety and digital pathology capabilities, Philips will continue to improve and adapt the DICOM export as the standard emerges.

Going forward, Philips intends to support both DICOM and iSyntax file formats for the Philips IntelliSite Pathology Solution.² This ensures a versatile solution to fulfill current and future pathology requirements so that interoperability will not be a concern for existing and new users. Philips will remain an active member of Working Group 26 to develop, test and adopt the best-suited standard for WSI Slides.
