Avalon FM20
Fetal Monitor
Avalon FM20
Fetal Monitor
Avalon FM fetal and maternal monitors are Philips first and only to offer automated coincidence detection (cross-channel verification) using Smart Pulse. It measures the fetal & maternal heart rates separately to enhance diagnostic confidence.
Features
Variety of readings for comprehensive understanding
This antepartum and intrapartum monitor provides a wide range of readings. These include separate maternal pulse measurement; integrated monitoring of maternal pulse rate and blood pressure; external monitoring of fetal heart rates, uterine activity, and fetal movement; and an extensive set of internal fetal parameters such as direct fetal heart rate and uterine pressure. Maternal SpO2 monitoring is included as standard.
NST Trace Interpretation to improve efficiency
Built-in NST Trace Interpretation, a clinical decision support (CDS) application for antepartum monitoring, can help to improve efficiency by sorting out the traces that require closer analysis by the obstetrician.
Smart Pulse for automated coincidence detection
Smart Pulse provides cross-channel verification. It continuously compares all fetal and maternal heart rates to enhance confidence that each is measured separately.
Specifications
- Battery
- Operating time (optional)
- Up to four
- General
- Care stage
- Antepartum
- Patient type
- Fetal and maternal
- Waveforms
- Not for diagnostic use
- MECG
- Parameters
- External fetal parameters
- US/Toco
- Twin capability
- Standard
- Triplets capability
- Optional
- Internal fetal parameters
- N/A
- Maternal parameters
- MECG, NIBP, Pulse
- Smart Pulse technology
- Standard
- Cross channel verification
- Standard
- Fetal movement profile
- Standard
- Interfaces
- PS/2 interfaces
- Optional
- Interfaces
- System interface (optional)
- Serial, LAN
- Readings
- NST trace interpretation (optional)
- Up to three Fetal Heart Rates (FHR)
- NST timer
- Standard
- Data storage
- Data buffer
- Up to one
- Weight
- Weight without battery option
- 11.2 lbs/5.1 kg
- Weight with battery option
- 11.7 lbs/5.3 kg
- Display
- Monitor screen display
- 6.5 in/16.51 cm
- Touchscreen operation
- Optional
