Ingenia MR-RT XD
Versatility to fit your planning
Ingenia MR-RT XD
Versatility to fit your planning
The Philips Ingenia MR-RT XD platform harnesses the power and value of MRI for radiation therapy planning. It has been designed around the needs of radiation oncology, with ease-of-use, streamlined integration, and versatility in mind.
Central to that concept is the ability to define a tailored approach with customizable functionality that meets your individual clinical, workflow, and budgetary requirements – all to provide better patient care.
Clinical image gallery
- 3D BrainView
- DWI XD TSE
- T1W and T2W contrasts - brain
- mDIXON
- 3D Vane XD
- T1W and T2W contrasts – head and neck
- MRCAT Pelvis
- MRCAT Brain
Features
Advanced imaging capabilities
The Ingenia MR-RT has full diagnostic capabilities to confidently tackle your complex radiotherapy imaging challenges. Advanced imaging techniques, such is distortion free diffusion with DWI XD TSE, robust-motion free imaging with 3D Vane and metal artefact reduction with O-MAR, help to refine your patient-centric planning tactics.
MR-only radiotherapy planning
The Ingenia MR-RT XD platform’s MR-only radiotherapy capability turns your MR into an authentic single modality simulator. With innovative MRCAT (MR for Calculating ATtenuation), you can obtain CT-like density information for dose calculations and position verification based on a single MR scan. So you can eliminate cumbersome and error-prone CT-MR registration, and make MR-based workflows more cost-efficient.
Position with precision
Ingenia MR-RT allows for accurate, reproducible patient positioning in treatment setup with an advanced couchtop design and tiltable Anterior Coil Support.
Equipped with multi-indexing support, the RT CouchTop XD has one-to-one compatibility with various linacs and accommodates a variety of MRI-compatible immobilization accessories to match your procedural approach.
Specifications
- Features
- Ingenia MR systems
- Ambition 1.5T, Elition 3.0T, Evolution 1.5T, Ingenia 1.5T/3.0T
- Bore design
- 70cm
- Geometric imaging accuracy
- ≤ 1 mm in Ø 32 cm volume (typical)
- RT CouchTop XD multi-indexing
- 14cm indexing and Elekta Unity Indexing system (2cm increments)
- Coil arrangements
- dStream FlexCoverage Anterior Coil, Posterior Coil, and FlexCoils L
- Diagnostic head coil compatibility
- Yes
- Applications supported
- Brain, head and neck, pelvis, thorax, abdomen, spine
- Patient immobilization accessories
- Order via 3ʳᵈ party vendors incl. CIVCO, Orfit, Qfix, Elekta, MacroMedics
- Patient transport
- Yes, with FlexTrak trolley
- Geometric QA
- Yes, large field of view QA phantom and automated analysis
- Optional external laser positioning system
- Type
- LAP DORADOnova MR3T or APOLLO MR3T compatible
- Allowed width range
- 2.594 - 5.000 m
- Laser phantom
- LAP Aquarius phantom and phantom holder, ELPS QA Test ExamCard
Related products
- Big Bore RT is designed as a CT simulator to enhance clinical confidence, accelerate time to treat and maximize value of its investment without compromising on patient experience – four dimensions that are essential towards excellent care.
- Based on its new, revolutionary fully sealed BlueSeal magnet, Ingenia Ambition X lets you experience more productive¹ helium-free MR operations. The Ingenia Ambition X delivers superb image quality even for challenging patients, and performs MRI exams up to 50% faster² with Compressed SENSE accelerations for all anatomies, in both 2D- and 3D scanning. Fast overall exam-time is achieved by simplifying patient handling at the bore with the touchless guided patient setup. Furthermore, the Ingenia Ambition offers an immersive audio-visual experience to help calm patients and guide them through MR exams.
- As a plug-in clinical application to Ingenia MR-RT, MRCAT Prostate + Auto-Contouring provides attenuation maps and automated, MR-based contours of prostate and organs at risk in as little as 20 minutes – all in a repeatable ‘one-click’ workflow.
- MRCAT Pelvis lets you plan radiation therapy using MRI as a single modality solution. Within just one MR exam, MRCAT Pelvis provides excellent soft-tissue contrast for target and OAR delineation, and continuous Hounsfield units for dose calculations. MRCAT (MR for Calculating ATtenuation) data can be used for export to treatment planning systems for CT-equivalent** dose calculations. In addition, MR-based imaging enables CBCT-based positioning based on soft-tissue contrast with the look and feel of CT.
- MRCAT Brain clinical application allows the use of MRI as the primary imaging modality for radiotherapy planning of primary and metastatic tumors in the brain without the need for CT. Detailed anatomical information for contouring and attenuation maps for dose calculations are both obtained from a single, submillimeter resolution 3D T1W mDIXON MR sequence. Artificial Intelligence (AI) is used for fast computation of continuous Hounsfield units directly on the MR console.
Disclaimer
1. Compared to Philips scans without Compressed SENSE
2. Compared to the Ingenia 1.5T ZBO magnet
MRCAT H&N may not be available in all markets
